Angelas™ Portable Medical Diode Laser

The Angelas™ portable medical laser is the newest Class IV grade laser available in the medical marketplace today. It includes the optimal range of wavelengths, with interchangeable handpiece optics.

This laser device can be used to perform in deep tissue laser therapy, podiatry, veterinary, spider vein removal, dentistry, and so on.


finger switch


7-inch interaction interface


exchangeable heads

  • Portable design

    Small size, lightweight and portable with modular design.
    Finger switch for convenient treatment and true portability. ①

  • Advanced design

    Internal fiber connecter for little maintenance.

  • Intuitive interface

    7-inch, clear and large enough for easy touch. ②
    Complete preset protocols for different patients or animals.

  • Ergonomic handpiece

    Easy replacement for different heads. ③

  • Li-ion rechargeable battery

    Can be used in different treatment scenarios for a long time.

  • Safe cable storage

    Anticlockwise widing solution for safer transport and storage. ①

  • Ergonomic back handle

    Designed for easy mobility and portability. ②

  • Multi-Functional

    Different combinations of wavelengths and powers.
    Multiple and exchangeable heads can meet different clinical demands.


safe cable storage


ergonomic back handle

Technique Specification
Product ModelAngelas™
Laser TypeGaAlAs Diode
Laser SystemClass IV
Wavelength980nm | 810nm | 810nm+980nm
Power10W/15W/25W | 15W/9W | 15W+15W
Operation ModeCW / Single Or Repeat Pulses
Pulse Duration10us-3s
Repetition Rate1Hz-20KHz
lP Degree of ProtectionFoot switch (waterproof): IPX8
Aiming Beam650nm, Power<5mW
Control ModeTrue Color Touch Screen (7 inches, resolution 600*1024)
Transmission SystemMedical Fibers With SMA905 Connector
Power Supply100V-240V~at 2.0A
